| Specification | Details |
|---|---|
| Product Name | Ubiquiti Dream Machine Beast |
| Model | UDM-Beast |
| Product Type | UniFi Cloud Gateway |
| Form Factor | 1U Rackmount |
| UniFi Applications | Network, Protect, Access, Talk and Connect |
| Managed UniFi Devices | 750+ |
| Simultaneous Connected Users | 7,500+ |
| Managed Cameras | 100 HD, 60 2K or 40 4K |
| Managed Access Hubs | Up to 200 |
| Maximum WAN Port Count | 8 |
| Default WAN Ports | 1× 25G SFP28 and 1× 10GbE RJ45 |
| 1GbE RJ45 Ports | 2 (1G/100M/10M) |
| 10GbE RJ45 Ports | 8 (10G/5G/2.5G/1G/100M) |
| 10G SFP+ Ports | 2 (10G/1G) |
| 25G SFP28 Ports | 2 (25G/10G/1G) |
| Console Port | 1 |
| IDS/IPS Throughput | 25Gbps |
| MAC Address Table | 32,000 |
| Firewall | Stateful and application-aware Layer 7 firewall |
| Traffic Inspection | DPI and traffic identification |
| Security Filtering | Zone-based filtering, content filtering, ad blocking and IDS/IPS |
| IDS/IPS Signatures | 55,000+ with CyberSecure |
| SD-WAN | License-free SD-WAN and Site Magic |
| VPN | IPsec, OpenVPN, WireGuard, L2TP and Teleport |
| Dynamic Routing | OSPF and BGP |
| High Availability | Shadow Mode (VRRP), gateway failover and DC power backup |
| Multi-WAN | Load balancing and policy-based WAN routing |
| Other Networking Features | LACP, advanced QoS, mDNS, advanced NAT, RADIUS, RadSec, DHCP and IGMP proxy |
| NVR Storage | 2× 3.5-inch NVR HDD bays |
| Integrated Storage | 128GB SSD |
| Processor | Octa-core ARM v9 at 2.1GHz |
| System Memory | 16GB |
| Display | 1.3-inch touchscreen |
| Management | Ethernet and Bluetooth |
| Power Method | 100–240V AC and USP-RPS DC input |
| Internal Power Supply | 150W AC/DC |
| Maximum Power Consumption | 100W |
| Heat Dissipation | 342 BTU/hr |
| Dimensions | 442.4 × 43.7 × 325mm |
| Weight | 5.5kg |
| Enclosure Material | CNC aluminium and SGCC steel |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 5% to 95% non-condensing |
| NDAA Compliant | Yes |
| Certifications | CE, FCC and IC |
Sale!
Networking
Ubiquiti Dream Machine Beast
Original price was: 7,100.00.
7,000.00Current price is: 7,000.00.
The Ubiquiti Dream Machine Beast UDM-Beast is a high-performance UniFi Cloud Gateway designed for enterprise networks and demanding deployments. It delivers up to 25Gbps IDS/IPS throughput, eight 10GbE RJ45 ports, two 10G SFP+ ports and two 25G SFP28 ports. With the full UniFi application suite, dual 3.5-inch NVR drive bays, a built-in 128GB SSD and high-availability support, the UDM-Beast combines advanced routing, network security, surveillance management and centralized UniFi control in a 1U rackmount system.
Warranty: 1 Year
FAQ
What is the Ubiquiti Dream Machine Beast UDM-Beast?
The UDM-Beast is a high-performance UniFi Cloud Gateway with 25Gbps IDS/IPS throughput, multi-gigabit Ethernet and SFP connectivity, advanced network security, and the full UniFi application suite.
What is the IDS/IPS throughput of the UDM-Beast?
The Ubiquiti Dream Machine Beast provides up to 25Gbps IDS/IPS throughput according to the official technical specifications.
How many Ethernet ports does the UDM-Beast have?
It has two 1GbE RJ45 ports and eight 10GbE RJ45 ports, plus two 10G SFP+ ports, two 25G SFP28 ports and a console port.
Does the UDM-Beast have 25G SFP28 connectivity?
Yes. It has two 25G SFP28 ports that support 25G, 10G and 1G connections with compatible equipment and transceivers.
Which UniFi applications does the UDM-Beast support?
It supports UniFi Network, Protect, Access, Talk and Connect through its integrated UniFi application suite.
How many UniFi devices can the UDM-Beast manage?
Ubiquiti specifies support for more than 750 managed UniFi devices and over 7,500 simultaneously connected users. Actual capacity depends on network design and workload.
Can the UDM-Beast record security camera footage?
Yes. It supports UniFi Protect and includes two 3.5-inch NVR drive bays and a built-in 128GB SSD. Compatible hard drives must be installed for additional NVR recording storage.
Does the UDM-Beast support high availability?
Yes. It supports Shadow Mode using VRRP, gateway failover and DC power backup options for supported deployments.
Is the UDM-Beast suitable for enterprise networks?
Yes. Its 25Gbps IDS/IPS throughput, 10GbE and 25G interfaces, advanced routing, security features and high-availability options make it suitable for demanding enterprise deployments.
