| Specification | Details |
|---|---|
| Product | Ubiquiti UniFi U7 Lite |
| Model | U7-Lite |
| Product Type | Dual-Band WiFi 7 Access Point |
| WiFi Standard | WiFi 7 (802.11be) |
| Spatial Streams | 4 |
| Frequency Bands | 2.4 GHz + 5 GHz |
| 6 GHz Support | No |
| 2.4 GHz MIMO | 2 × 2 DL/UL MU-MIMO |
| 5 GHz MIMO | 2 × 2 DL/UL MU-MIMO |
| 2.4 GHz Maximum Data Rate | 688 Mbps (40 MHz) |
| 5 GHz Maximum Data Rate | 4.3 Gbps (240 MHz) |
| Maximum Aggregate Wireless Rate | Approximately 5.0 Gbps |
| Coverage Area | 115 m² (1,250 ft²) |
| Maximum Client Count | 200+ |
| Uplink | 1 × 2.5GbE RJ45 |
| Supported Ethernet Speeds | 2.5G / 1G / 100M / 10M |
| Power Method | PoE |
| Supported Voltage Range | 42.5–57V DC |
| Maximum Power Consumption | 13W |
| 2.4 GHz Antenna Gain | 4 dBi |
| 5 GHz Antenna Gain | 5 dBi |
| 2.4 GHz Maximum TX Power | 23 dBm |
| 5 GHz Maximum TX Power | 24 dBm |
| Maximum BSSIDs | 8 per radio |
| Channel Bandwidth | HT 20/40, VHT 20/40/80/160, HE 20/40/80/160, EHT 20/40/80/160/240 MHz |
| Wireless Meshing | Yes |
| Band Steering | Yes |
| 802.11k Radio Resource Management | Yes |
| 802.11r Fast Roaming | Yes |
| 802.11v BSS Transition Management | Yes |
| Advanced Radio Management | Yes |
| Passpoint | Yes |
| Captive Hotspot Portal | Yes |
| Custom Branding Landing Page | Yes |
| Voucher Authentication | Yes |
| Payment-Based Authentication | Yes |
| External Portal Server Support | Yes |
| Password Authentication | Yes |
| Guest Network Isolation | Yes |
| Private Pre-Shared Key (PPSK) | Yes |
| WiFi Speed Limiting | Yes |
| Client Device Isolation | Yes |
| WiFi Schedules | Yes |
| RADIUS over TLS (RadSec) | Yes |
| Dynamic RADIUS VLAN | Yes |
| Management | UniFi Network |
| Management Interface | Ethernet |
| Mounting | Ceiling / Wall |
| Mount Included | Lite Mount Included |
| Enclosure Material | UV-Stabilized Polycarbonate |
| Mount Material | UV-Stabilized Polycarbonate, Galvanized Steel (SGCC) |
| Dimensions | Ø171.5 × 33 mm |
| Weight | 313 g |
| System LED | White / Blue |
| Operating Temperature | -30°C to 40°C |
| Operating Humidity | 5%–95% non-condensing |
| NDAA Compliant | Yes |
| Certifications | CE, FCC, IC |
| UniFi Network Requirement | Version 9.0.114 or later |
Sale!
Wireless Access Points
Ubiquiti Unifi U7-Lite
Original price was: 448.00.
440.00Current price is: 440.00.
The Ubiquiti UniFi U7 Lite is a compact dual-band WiFi 7 access point designed for homes, offices, retail stores, classrooms and small to medium-sized business networks. It provides up to 4.3 Gbps on 5 GHz and 688 Mbps on 2.4 GHz, with 4 spatial streams and a 2.5GbE Ethernet uplink.
With support for WiFi 7, WiFi 6, WiFi 5 and WiFi 4 clients, the U7 Lite provides a modern wireless upgrade while maintaining compatibility with existing devices. It supports up to 200+ clients and offers coverage of up to 115 m² (1,250 ft²) under Ubiquiti’s specified conditions.
Warranty: 1 Year
Out of stock
FAQ
What is the Ubiquiti UniFi U7 Lite?
The Ubiquiti UniFi U7 Lite is a compact dual-band WiFi 7 access point with 4 spatial streams, 2.5GbE Ethernet and PoE power. It is designed for homes, offices and business wireless networks.
What is the maximum speed of the U7 Lite?
The U7 Lite supports up to 4.3 Gbps on 5 GHz and up to 688 Mbps on 2.4 GHz under the specified WiFi 7 channel and modulation conditions.
Does the U7 Lite support 6 GHz?
No. The U7 Lite is a dual-band WiFi 7 access point operating on 2.4 GHz and 5 GHz. It does not include a 6 GHz radio.
How many clients can the U7 Lite support?
Ubiquiti specifies the U7 Lite for 200+ clients. Actual performance depends on client devices, traffic, RF interference and network configuration.
What is the coverage area of the U7 Lite?
The U7 Lite has a specified coverage area of up to 115 m² (1,250 ft²). Actual coverage depends on building construction, access point placement, interference and client device capabilities.
Does the U7 Lite have a 2.5GbE port?
Yes. The U7 Lite has one 2.5GbE RJ45 Ethernet uplink.
Does the U7 Lite support PoE?
Yes. The U7 Lite uses PoE for power and has a maximum power consumption of 13W.
Can the U7 Lite be mounted on a wall or ceiling?
Yes. The U7 Lite supports both ceiling and wall mounting, with the Lite Mount included.
Can the U7 Lite be managed through UniFi Network?
Yes. The U7 Lite is managed through the UniFi Network platform and requires UniFi Network version 9.0.114 or later according to the current Ubiquiti specifications.
