Sale!
Ubiquiti silver rackmount switch with display and SFP ports on white background.

Ubiquiti UniFi Pro XG 10 PoE EU

Original price was:  3,330.00.Current price is:  3,320.00.

Ubiquiti UniFi Pro XG 10 PoE EU (USW-Pro-XG-10-PoE) is a professional 1U Layer 3 managed switch designed for high-speed enterprise and professional networks. It provides 10 × 10GbE RJ45 PoE+++ ports supporting up to 90W per port, 2 × 10G SFP+ uplink ports, a 400W PoE budget, 240 Gbps switching capacity and 179 Mpps forwarding performance. The switch also features Etherlighting, a 1.3-inch touchscreen, Layer 3 routing, UniFi Network management, and USP RPS DC power-backup support.

Warranty: 1 Year
Category: Brand:
Enquire Now
Specification Details
Product Ubiquiti UniFi Pro XG 10 PoE EU
Model USW-Pro-XG-10-PoE
Product Type Layer 3 Managed PoE+++ Switch
Form Factor 1U Rack Mount
RJ45 Ports 10 × 10GbE
RJ45 Port Speeds 10G / 5G / 2.5G / 1G / 100M
PoE Ports 10 × PoE+++
SFP+ Ports 2 × 10G SFP+
PoE Standards IEEE 802.3af / 802.3at / 802.3bt
Maximum PoE per Port 90W
Total PoE Availability 400W
Switching Capacity 240 Gbps
Total Non-Blocking Throughput 120 Gbps
Forwarding Rate 179 Mpps
Supported VLANs 1,000
MAC Address Table 32,000
IPv4 Static Routes 256
Packet Buffer 2 MB
IPv4 Access Lists 128
MAC Access Lists 128
Layer 3 Yes
Inter-VLAN Routing Yes
Static Routing Yes
DHCP Server Yes
DHCP Relay Yes
LACP Port Aggregation Yes
STP / RSTP Yes
QoS DSCP
IGMP Snooping Yes
Advanced IGMP Configuration Querier / Fast Leave / Router Port
802.1X Control Yes
MAC-Based ACLs & Device Isolation Yes
DHCP Snooping & Guarding Yes
Egress Rate Limit Yes
Flow Control Yes
Storm Control Yes
Multicast & Broadcast Rate Limiting Yes
MAC Address Blocking Yes
IP-Based ACLs & Network Isolation Yes
Port Restriction Yes
Port Isolation Yes
Port Mirroring Yes
Jumbo Frames Yes
LLDP-MED Yes
Voice VLAN Yes
Loop Protection Yes
Virtual Network Override Yes
Pro AV Profiles Play / Dante / Q-SYS / NDI / SDVoE / Shure / AES67 / Crestron
Etherlighting Ethernet + SFP+
LCM Display 1.3-inch Touchscreen
Power Method 100–240V AC, 50/60 Hz
Internal Power Supply 550W AC/DC
USP RPS Support Yes
Maximum Power Consumption 65W excluding PoE output
Maximum Power Including PoE Output 520W
Supported Voltage Range 100–240V AC
Enclosure Material SGCC Steel
Mount Material SGCC Steel
Supported Rack Depth 400–1200 mm
Dimensions 442.4 × 285 × 44 mm
Weight Without Mounting Brackets 4.6 kg
Weight With Mounting Brackets 4.7 kg
ESD Protection Air: ±30 kV / Contact: ±30 kV
Operating Temperature -5°C to 40°C
Operating Humidity 10%–90% non-condensing
NDAA Compliant Yes
Certifications CE, FCC, IC, Anatel
UniFi Network Requirement Version 9.1.120 and later

FAQ

What is the Ubiquiti UniFi Pro XG 10 PoE?

The Ubiquiti UniFi Pro XG 10 PoE is a professional-grade Layer 3 managed switch with ten 10GbE PoE+++ ports and two 10G SFP+ ports, designed for high-performance enterprise networks.

How many PoE ports does the Pro XG 10 PoE have?

The Pro XG 10 PoE provides 10 PoE+++ ports with support for up to 90W per port and a total PoE budget of up to 400W.

Does the UniFi Pro XG 10 PoE support 10GbE?

Yes. All 10 RJ45 ports support 10GbE connectivity, while the switch also includes two 10G SFP+ ports for high-speed uplinks and network aggregation.

Does the Pro XG 10 PoE support Layer 3 networking?

Yes. The switch supports Layer 3 features including inter-VLAN routing, static routing, DHCP server and DHCP relay, making it suitable for advanced enterprise network deployments.
