| Specification | Details |
|---|---|
| Product | Ruijie Reyee RG-RAP52-OD |
| Product Type | Outdoor Dual-Band Wi-Fi 5 Access Point |
| Wi-Fi Standard | IEEE 802.11a/b/g/n/ac |
| Wi-Fi Generation | Wi-Fi 5 |
| Frequency Bands | 2.4 GHz + 5 GHz |
| 6 GHz Support | No |
| Radio Design | Dual-radio, 4 spatial streams |
| 2.4 GHz MIMO | 2 × 2 MIMO |
| 5 GHz MIMO | 2 × 2 MIMO |
| 2.4 GHz Wireless Rate | 400 Mbps |
| 5 GHz Wireless Rate | 866 Mbps |
| Maximum Wireless Data Rate | 1266 Mbps |
| Antennas | 2 × external omnidirectional antennas |
| Ethernet Port | 1 × 10/100/1000BASE-T Gigabit Ethernet |
| Power Supply | PoE / PoE+ |
| Local Power Supply | No |
| Maximum Power Consumption | 13.5W |
| Maximum Associated Clients | 64 on 2.4 GHz; 110 on 5 GHz; 110 with both bands enabled |
| Maximum Managed Devices | 300 |
| MU-MIMO | Yes |
| Reyee Mesh | Yes |
| Layer 2 Roaming | Yes |
| Layer 3 Roaming | Yes |
| Self-Organizing Network | Yes |
| Cloud Management | Ruijie Cloud / Reyee App |
| Cloud Portal Authentication | Yes |
| Remote Monitoring and Maintenance | Yes |
| IPv6 | No |
| Mounting | Wall / Pole |
| Outdoor Protection | IP65 |
| Operating Temperature | -30°C to 65°C |
| Color | White |
| Dimensions | 50 × 35.7 × 220 mm, excluding mounting bracket and antenna |
| Antenna Length | 185 mm |
| Weight | ≤ 0.4 kg |
Sale!
Networking
RG-RAP52-OD
Original price was: 326.00.
320.00Current price is: 320.00.
The Ruijie Reyee RG-RAP52-OD is a dual-band Wi-Fi 5 outdoor access point designed for reliable wireless coverage in villas, retail stores, restaurants, campuses, outdoor business areas and other demanding environments. It supports 2.4 GHz and 5 GHz wireless connectivity with a combined maximum wireless rate of up to 1266 Mbps.
Featuring 2×2 MIMO on both frequency bands, detachable omnidirectional antennas, Reyee Mesh, AI Roaming and cloud management, the RG-RAP52-OD provides flexible wireless deployment for outdoor and semi-outdoor networks. Its IP65 weatherproof enclosure and wall/pole mounting options make it suitable for outdoor installations in Dubai and across the UAE.
Warranty: 1 Year
FAQ
What is the Ruijie Reyee RG-RAP52-OD?
The RG-RAP52-OD is a dual-band Wi-Fi 5 AC1300 outdoor access point from Ruijie Reyee, designed for outdoor wireless coverage, Mesh networking and business deployments.
What is the maximum speed of RG-RAP52-OD?
The RG-RAP52-OD has a maximum combined wireless rate of 1266 Mbps, consisting of up to 400 Mbps on 2.4 GHz and 866 Mbps on 5 GHz.
Does RG-RAP52-OD support Wi-Fi 6?
No. The RG-RAP52-OD is a Wi-Fi 5 / IEEE 802.11ac Wave 2 access point. It does not support Wi-Fi 6 or 6 GHz Wi-Fi.
What is the outdoor range of RG-RAP52-OD?
Ruijie’s datasheet lists an ideal maximum coverage range of up to 300 metres on 2.4 GHz and 400 metres on 5 GHz. Actual coverage depends on obstacles, interference, mounting position and client devices.
Is the RG-RAP52-OD waterproof?
The RG-RAP52-OD has an IP65 outdoor protection rating. It is designed for appropriate outdoor installations and protection against dust and water jets.
Does RG-RAP52-OD support PoE?
Yes. The RG-RAP52-OD supports IEEE 802.3af and 802.3at PoE. Ruijie also specifies support for a 24V passive PoE injector.
Can RG-RAP52-OD be mounted on a pole?
Yes. The access point supports both wall and pole mounting.
Does RG-RAP52-OD support Reyee Mesh?
Yes. The RG-RAP52-OD supports Reyee Mesh and AP Mesh for compatible wireless network deployments.
Does RG-RAP52-OD have detachable antennas?
Yes. The RG-RAP52-OD uses detachable external omnidirectional antennas with 3 dBi gain on 2.4 GHz and 4 dBi gain on 5 GHz.
